40ppm (A4)/ 20ppm (A3), 2,400 x 600dpi, USB 2.0, 768MB RAM, FPOT 9.3 sec., Duplex and Network Ready, UFRII, PCL, PS, MEAP

Monthly Duty Cycle: 300,000 pages

(1 + 2 years on-site warranty)



Consumable

Toner: CART 333 (10,000 pages)/ CART 333H (17,000 pages)



Print
Printing Method	Monochrome Laser Beam Printing
Fixing Method	On Demand Fixing
Print Speed	Mono: A4 / A3	40ppm / 20ppm
	Duplex: A4	40ppm (20spm; sheets per minute)
Print Resolution	600 x 600dpi
Print Quality with Image Refinement	1200 x 1200dpi (equivalent)  2400 (equivalent) x 600dpi
Warm-Up Time	From Power On:	29secs. or less
	From Quick Start:	17secs. or less
Recovery Time (From Sleep Mode)	Panel Off:	0secs.
	Deep Sleep:	10secs. or less
Print Language	UFRII, PCL5e/6, PostScript 3, PDF, XPS
Standard Fonts	PCL: 93 fonts PS / PDF: 136 fonts
Auto Duplex Print	Standard
Available Paper Size for Auto Duplex Print	A3, B4, A4, A4R, B5, A5, Ledger, LTR, LTR-R, Legal *1, Exe,
Print Margins	5mm-top, bottom, left and right (Envelope: 10mm)
Direct Print (via USB Host 2.0)	TIFF, JPEG, PDF, XPS
Paper Handling
Paper Input	Standard Cassette: (Based on 60-84g/m2)	250 sheets
	Multi-Purpose Tray: (Based on 60-90g/m2)	100 sheets
	Optional Paper Feeder PF-A1: (Based on 60-74g/m2)	550 sheets (max. 3 units)
	Maximum Paper Input Capacity (Based on 60-74g/m2):	2,000 sheets
Paper Size	Standard Cassette:	A3, B4, A4, A4R, B5, A5, Ledger, LTR, LTR-R, Legal*1, Exe, foolscap, 8K, 16K,  Custom Size available *2
	Multi-Purpose Tray:	A3, B4, A4, A4R, B5, A5, Ledger, LTR, LTR-R, Legal*1, Exe, STMT, foolscap, 8K, 16K,  Custom Media: 210.0 - 297.0mm x 470.1 - 1200mm (only with UFR II printer driver)
	Optional Paper Feeder PF-A1:	A3, B4, A4, A4R, B5, A5^, Ledger, LTR, LTR-R, Legal*1, Exe, STMT, foolscap, 8K, 16K,  Custom Size available *2 ^ optional Universal Cassette UC-A1 and UFR II printer driver are required
Paper Type	Plain, Heavy, Recycled, Color, Transparency, Label, Envelope
Paper Weight	Standard Cassette:	60~120g/m2
	Multi-Purpose Tray:	60~199g/m2
	Optional Paper Feeder PF-A1:	60~120g/m2
Paper Output (Based on 64g/m2)	Face-Down:	250 sheets
	Face-Up:	50 sheets
Connectivity and Software
Standard Interface	USB 2.0 High Speed, USB 2.0 Host (2 ports), 10 / 100 Base-T / 1000 Base-T Ethernet
Expansion Interface	SD Card Slot
Compatible Operating Systems *3	Windows XP (32bit / 64bit), Windows Vista (32bit / 64bit), Windows 7 (32bit / 64bit), Windows 8 (32bit / 64bit), Windows Server 2003 (32bit / 64bit), Windows Server 2008 (32bit / 64bit), Windows Server 2008 R2 (64bit), Windows Server 2012 (64bit), Mac OS 10.6~10.8.x *4, Linux*4, Citrix
Security & Other Features
Security Function	IPSec, IEEE802.1x, Secure Print (with optional SD Card)
Support	MEAP function
Mobile Print	Canon Mobile Printing
General Specification
Memory (RAM)	768MB
LCD Display	5-line LCD
Dimensions (W x D x H)	514 x 532 x 303mm
Weight	Approx. 25.8kg (without cartridge)
Power Consumption	Maximum:	1420W
	During Operation:	Approx. 670W (Average)
	During Standby:	Approx. 38W (Average)
	During Sleep 1:	Approx. 38W
	During Sleep 2:	Approx. 12W
	During Sleep 3:	Approx. 1.1W
Energy Star TEC (Typical Electricity Consumption)	2.2kWh / week
Noise Level	During Operation:	Sound Power Level : 7.30B or less Sound Pressure Level (Bystander's position): 56dB
	During Standby:	Sound Power Level: Inaudible Sound Pressure Level: Inaudible
Operating environment	Temperature：	10~30°C
	Humidity：	20~80%RH (no condensation)
Power requirement	AC 220V- 240, 50 / 60Hz
Toner Cartridge*5	Cartridge 333:	10,000 pages
	Cartridge 333 H:	17,000 pages
Monthly Duty Cycle*6	Up to 300,000 pages
Optional Accessories
Paper Feeder	Paper Feeder PF-A1 (550-sheets)
Universal Cassette	Universal Cassette UC-A1 *7
Barcode ROM	Barcode Printing Kit-F1
Secure Print	Canon SD Card-B1 (8GB)

*1	Legal refers to paper measuring 215.9 x 355.6mm (8.5 x14 inches).
*2	The supported custom size may differ depending on the installed print language.
*3	Check here for updates on available printer driver.
*4	Drivers for Mac OS or Linux can be downloaded here when available.
*5	Declared yield in accordance with ISO/IEC 19752.
*6	Monthly duty cycle value provides a means for comparison of product robustness in relation to other Canon laser devices, and does not refer to actual maximum image output per month.
*7	The Universal Cassette UC-A1 is required to enable A5 printing from the Optional Paper Feeder PF-A1.
